Teknisk Specifikation
Artikelnr
T383GN
Hjul
Alloy, Tubeless, 700c, 21c
Headset
FSA 1-1/2" Integrated Aluminium Cup
Styre
OC Road Performance RP21 Alu SL, Reach 80, Drop 125
Bakväxel
Shimano Cues U6020 SGS Shadow
Ram
Orbea Gain Carbon OMR monocoque structure, Integrated Seat clamp with STVZO light, ICR cable routing, Thru Axle 12x142mm rear, thread M12x2 P1, Flat Mount disc, 700x35 max tyre, BB386 EVO, Mahle X20 AMC plug.
Baknav
Orbea Thru Axle 12x142mm M12x2 P1 Lite
Vevlager
Shimano Cues U6040 34x50t
Framnav
Orbea Thru Axle 12x100mm M12x2 P1 Lite
Baklampa
Rear position light, on saddle clamp, COB Led, On/Off, 12 Lumen. STVZO
Framlampa
Front position light, on display holder, COB Led, On/Off, 60 Lumen, ECE50.
Serie
GAIN
Sadelstolpe
OC Performance XP10-S Carbon, 27.2mm, Setback 20
Sadel
Fizik Aliante R5
Vevparti
Shimano Cues U6040 34x50t
Växelreglage
Shimano U6030
Styrstam
OC Road Performance RP10, -8º
Framgaffel
Gain OMR carbon fork, 700x35 maximun tyre, Flat Mount disc, Thru Axle 12x100mm, thread M12x2 P1
Motor
Mahle motor hub X20, ALC
Kedja
Shimano LG500
Kassett
Shimano CS-LG400 11-39t 10-Speed
Årsmodell
2026
Batteri
Mahle iX350 36V 353Wh
Bromsar
Shimano U6030 Hydraulic Disc
Däck
Pirelli P ZERO™ Race X SmartEVO TLR 700x30c
Display
Mahle Pulsar One monochrome ANT+ LEV
