Teknisk Specifikation
Artikelnr
S308GN
Bakväxel
Shimano 105 Di2 R7150
Ram
Orbea Gain Carbon OMR monocoque structure, Integrated Seat clamp with STVZO light, ICR cable routing, Thru Axle 12x142mm rear, thread M12x2 P1, Flat Mount disc, 700x35 max tyre, BB386 EVO, Mahle X20 AMC plug.
Baknav
Orbea Thru Axle 12x142mm M12x2 P1 Lite
Framnav
Orbea Thru Axle 12x100mm M12x2 P1 Lite
Framlampa
Rear position light, on saddle clamp, COB Led, On/Off, 12 Lumen. STVZO
Serie
GAIN
Sadelstolpe
OC Performance XP10-S Carbon, 27.2mm, Setback 20
Gaffel
Gain OMR carbon fork, 700x35 maximun tyre, Flat Mount disc, Thru Axle 12x100mm, thread M12x2 P1
Sadel
Fizik Aliante R5
Vevparti
Shimano 105 R7100 34x50t
Växelreglage
Shimano Di2 R7170
Styrstam
OC Road Performance RP10, -8º
Rammaterial
CARBON
Framgaffel
Gain OMR carbon fork, 700x35 maximun tyre, Flat Mount disc, Thru Axle 12x100mm, thread M12x2 P1
Motorplacering
Mittmotor
Motor
Mahle motor hub X20, ALC
Kedja
Shimano M6100
HjulFälg
Alloy, Tubeless, 700c, 21c
Kassett
Shimano 105 R7100 11-34t 12-Speed
Hjulstorlek
700c
Årsmodell
2025
Batteri
Mahle iX350 36V 353Wh
Bromsar
Shimano R7170 Hydraulic Disc
Däck
Pirelli P ZERO™ Race SmartEVO TLR 700x30c
Display
Mahle Pulsar One monochrome ANT+ LEV
